Part Number: PM0037
Classification: Alkaline
Chemical System: Zinc-Manganese Dioxide (Zn/MnO 2)
Designation: ANSI-15A, IEC-LR6
Nominal Voltage: 1.5 volts
Nominal IR: 150 to 300 milliohms (fresh)*
Operating Temp: -18¡C to 55¡C (0¡F to 130¡F)
Typical Weight: 23.0 grams (0.8 oz.)
Typical Volume: 8.1 cubic centimeters (0.5 cubic inch)
Jacket: Plastic Label
Shelf Life: 7 years at 21¡C (80% of initial capacity)
Terminal: Flat Contact
